65" · 4K UHD · Android 13
Newline
Newline Vega Pro 86" 4K 40-Point Capacitive
SKU TT-8624Z
86-inch 4K interactive display with 40-point capacitive touch, built-in camera, Android 13, 450 cd/m² brightness for large conference spaces.
- Screen size
- 86"
- Resolution
- 4K UHD
- Touch
- 40 points
- System
- Android 13
Pricing
Price on request in OMR
Written quote usually within one business day
Download datasheet (PDF)
-
Written quotation in OMR
Pricing, availability and warranty on one document.
-
Manufacturer warranty
Terms confirmed on your quotation.
-
All 11 governorates
Delivered from Muscat to Dhofar.
-
Quotations in Arabic & English
Ask for Arabic, English or both.
The product, in detail.
Screen and picture
- Screen Size
- 86"
- Resolution
- 4K UHD
- Brightness
- 450 cd/m²
- Backlight
- Direct LED
Touch and writing
- Touch Points
- 40 points
- Touch Technology
- Capacitive
Built-in system
- Operating System
- Android 13
- Processor
- Arm Cortex-A73 × 4 + Cortex-A53 × 4
Description
Newline Vega Pro 86" delivers 4K UHD resolution with 40-point capacitive multi-touch and ±1mm touch accuracy for responsive collaboration across large spaces. The 450 cd/m² brightness and Anti-Glare Smooth Glass surface reduce fatigue during extended use. Built-in camera and integrated 55W speaker system (20W × 2 + 15W) enable video conferences and presentations without external equipment.
Android 13 with 8GB RAM and 128GB storage runs applications instantly. Dual Gigabit LAN ports and Wi-Fi 6 support fast network connectivity. Three HDMI 2.1 inputs and dual Type-C (100W + 15W power delivery) accommodate multiple source devices simultaneously. Blue light filter and proximity sensors enhance user comfort during extended sessions. Optional PC slot accepts embedded computing modules for dedicated kiosk applications.
Ideal for: Corporate board rooms, university lecture theaters, government meeting halls, and training centers across Oman requiring real-time multi-source annotation.
- Screen: 86" diagonal, 4K UHD, 178° viewing angles, Anti-Glare Smooth Glass
- Touch: 40-point capacitive, ±1mm accuracy, palm rejection enabled
- Brightness: 450 cd/m²; direct LED backlight with blue light filter
- Display inputs: HDMI 2.1 ×3, HDMI 2.0 ×1, DisplayPort 1.2, Type-C ×2 (100W/15W power)
- Audio/Video: Built-in camera, 55W speakers (20W stereo + 15W subwoofer), microphone in, audio out
- Computing: Android 13, ARM Cortex-A73 ×4 + A53 ×4, Mali-G52 GPU ×8, 8GB RAM, 128GB storage
Specifications
Manufacturer specifications · confirmed on your quotation
Display
- Screen Size
- 86"
- Resolution
- 4K UHD
- Brightness
- 450 cd/m²
- Backlight
- Direct LED
- Viewing Angle
- 178° (H) / 178° (V)
Touch
- Touch Technology
- Capacitive
- Touch Points
- 40 Points Multi Touch
System
- Operating System
- Android 13
- Processor
- Arm Cortex-A73 × 4 + Cortex-A53 × 4
Connectivity
- HDMI Input
- HDMI In 2.1 × 3
- HDMI Output
- HDMI Out 2.0 × 1
- USB Ports
- USB 3.2 Type-A × 4, USB Type-C 3.0 × 1, USB 3.2 Type-A Android × 1
- Ethernet
- Gigabit LAN (RJ45) × 2
- Bluetooth
- Bluetooth 5.2
Camera & audio
- Speaker Type
- Built-in Speakers
- Speaker Output
- 20 W × 2 + 15 W × 1
Physical & warranty
- Dimensions
- 1965 × 1184 × 95 mm
- Weight
- 59 kg
- Wall Mount
- 800 × 400 mm (VESA)
- Power Consumption
- 146 W
