Newline Naos+ 75" 4K Interactive Display, 400 cd/m²
SKU TT-7521IP
75-inch 4K interactive flat panel with 20-point capacitive touch, 400 cd/m² brightness, antimicrobial tempered glass, 3×HDMI inputs, dual 15W speakers.
- Screen size
- 75"
- Resolution
- 4K UHD
- Touch
- 20 points
- Processor
- MSD3683QTA
Pricing
Price on request in OMR
Written quote usually within one business day
Download datasheet (PDF)
-
Written quotation in OMR
Pricing, availability and warranty on one document.
-
Manufacturer warranty
Terms confirmed on your quotation.
-
All 11 governorates
Delivered from Muscat to Dhofar.
-
Quotations in Arabic & English
Ask for Arabic, English or both.
The product, in detail.
Screen and picture
- Screen Size
- 75"
- Resolution
- 4K UHD
- Brightness
- 400 cd/m²
- Backlight
- Direct LED
Touch and writing
- Touch Points
- 20 points
- Touch Technology
- Capacitive
Built-in system
- Processor
- MSD3683QTA
Description
The Newline Naos+ 75-inch model (TT-7521IP) delivers 4K UHD (3840×2160) resolution on a Direct LED backlight with 20-point capacitive multi-touch technology and ±1mm touch accuracy. Brightness reaches 400 cd/m² across a 178° viewing angle (H/V). The surface features anti-glare, anti-fingerprint, and antimicrobial tempered glass, addressing hygiene requirements in shared-use and medical environments.
Connectivity includes 3×HDMI In (4K60 Hz), 1×HDMI Out (4K60 Hz), 1×USB Type-C power (65W), 2×USB 3.0, 1×USB 2.0, 1×Gigabit Ethernet, 1×RS-232, and 3×USB Type-B touch ports. The MSD3683QTA media controller integrates 3GB RAM and 64GB storage for native video scheduling and playback without external PC. Dual 15W speakers deliver onboard audio. Stands on VESA 800×400mm mount. Weight is 49 kg; power draw measures 198W active, <0.5W in standby.
Ideal for: University and secondary school lecture spaces, healthcare patient education areas, corporate training laboratories, and public-sector meeting rooms where antimicrobial surfaces, high-output brightness, and integrated media control streamline deployment and reduce operational dependencies.
- Screen Size: 75 inches, 4K UHD (3840×2160)
- Touch: 20-point capacitive, ±1mm accuracy
- Brightness: 400 cd/m²
- Surface: Anti-glare, anti-fingerprint, antimicrobial tempered glass
- Inputs: 3×HDMI (4K60), 1×USB-C (65W), Gigabit Ethernet, RS-232
- Audio: 2×15W built-in speakers
- Storage/Control: MSD3683QTA, 3GB RAM, 64GB, native playback
- Power: 198W active, <0.5W standby; VESA 800×400mm, 49 kg
Specifications
Manufacturer specifications · confirmed on your quotation
Display
- Screen Size
- 75"
- Resolution
- 4K UHD
- Brightness
- 400 cd/m²
- Backlight
- Direct LED
- Viewing Angle
- 178° (H) / 178° (V)
Touch
- Touch Technology
- Capacitive
- Touch Points
- 20 Points Multi Touch
System
- Processor
- MSD3683QTA
Connectivity
- HDMI Input
- HDMI In (4K60 Hz) × 3
- HDMI Output
- HDMI Out (4K60 Hz) × 1
- USB Ports
- USB 2.0 (Embedded) × 1, USB 3.0 (Dynamic) × 2
- Ethernet
- Gigabit LAN (RJ45) × 1
Camera & audio
- Speaker Type
- Built-in Speakers
- Speaker Output
- 15W × 2
Physical & warranty
- Dimensions
- 1731,1 × 1010 × 86,3 mm
- Weight
- 49 Kg
- Wall Mount
- 800 × 400 mm (VESA)
- Power Consumption
- 198 W
Other
- Accessories
- 2 × PCAP Passive Pen
